Session Affinity (a.k.a. Sticky Sessions)

Illustration by Annie Ruygt of a machine sticking envelopes together

Overview

In a number of scenarios, it is important to ensure that certain requests are routed to a specific Machine. This frequently is expressed in the form of wanting an entire user’s session to be processed by the same Machine. There are two approaches to addressing this with Fly.io:

fly-force-instance-id - Client-side request header
fly-replay - Server-side response header

Fly-Force-Instance-Id

This approach requires you to have control over the client, typically a browser, but allows for immediate routing without an additional hop. The example below uses Rails’ Hotwire Turbo with Stimulus to send the required header. For this to work, the client needs some way of knowing what Machine to route requests to. This can be accomplished by adding attributes to the <body> tag in HTML responses. With Rails, those tags would be found in app/views/layouts/application.html.erb. An example <body> tag:

<body data-instance="<%= ENV['FLY_MACHINE_ID'] %>"
   data-controller="sticky-session">

These attributes identify the Machine instance to direct future requests to, and the name of the Stimulus controller to be used to make this happen. Place the following into app/javascript/controllers/sticky-session.js:

import { Controller } from "@hotwired/stimulus"

// Connects to data-controller="sticky-session"
export default class extends Controller {
  connect() {
    document.documentElement.addEventListener(
     'turbo:before-fetch-request',
     this.beforeFetchRequest
    )
  }

  disconnect() {
    document.documentElement.removeEventListener(
     'turbo:before-fetch-request',
     this.beforeFetchRequest
    )
  }

  beforeFetchRequest = event => {
    event.detail.fetchOptions.headers['fly-force-instance-id'] =
      this.element.dataset.instance;
  }
}

This code will subscribe and unsubscribe from turbo:before-fetch-request events and insert a fly-force-instance-id header into requests.

Fly-Replay

This approach is implemented entirely on the server. Your application examines each request, determines which Machine should handle it, and returns a fly-replay response header to route the request accordingly. Initial requests will require an additional “hop” to route, and requests are limited to payloads of 1 megabyte. The example below creates Express Middleware that routes requests based on a session cookie:

// Import required modules
import express from "express";
import cookieParser from "cookie-parser";

// Create an Express app
const app = express();

// Middleware to parse cookies
app.use(cookieParser());

app.use((request, response, next) => {
  // This assumes your application has already established a session using a session_id cookie via your session middleware.
  const sessionId = request.cookies["session_id"];

  if (!sessionId) {
    // No session - let any machine handle it
    next();
    return;
  }

  // Determine which machine should handle this session
  // This could be based on:
  // - Database lookup (session -> machine mapping)
  // - Consistent hashing of session ID
  // - Regional routing logic
  // - Load balancing algorithm
  // You'll need to implement determineTargetMachine() based on your routing strategy
  const targetMachineId = determineTargetMachine(sessionId);

  if (targetMachineId === process.env.FLY_MACHINE_ID) {
    // This is the correct machine - handle the request
    next();
  } else {
    // Route to the correct machine
    response.set('Fly-Replay', `instance=${targetMachineId}`);
    response.status(307);
    response.send();
  }
});

// Start the Express server
const port = 3000;
app.listen(port, () => {
  console.log(`Server is running on port ${port}`);
});

Optimizing with Replay Caching

For production workloads, having your application replay every request can create unnecessary load and latency. You can configure Fly Proxy to cache replay decisions, so only the first request in a session needs to consult your application. Add replay cache rules to your fly.toml:

[http_service]
  internal_port = 8080
  force_https = true

  [[http_service.http_options.replay_cache]]
    path_prefix = "/"
    ttl_seconds = 300
    type = "cookie"
    name = "session_id"

With this configuration:

The first request with a given session_id hits your app
Your app returns a fly-replay response
Fly Proxy caches this decision for that specific session_id value
For the next 5 minutes, requests with the same session_id are automatically routed without consulting your app

Caching is an optimization, not a guarantee, so your origin app still needs to handle replaying requests that aren’t routed by a cached replay. Replays can be cached on any existing cookie or request header. For sticky sessions with an API, for example, you might choose to cache based on the Authorization header. For complete details on replay caching configuration, see Session-based Replay Caching.
